It is for all position welding of 18%Cr-8%Ni austenitic stainless steel ASTM 304, 304L, 0Cr18Ni9 or equivalent steels.
- AWS A5.4/ASME SFA5.4: E308-17
- GB 983: E308-17
Literature
Literature
- Rutile-Basic stainless steel electrode
- Weldable on AC and DCEP
- Excellent weldability, stable arc
- Low susceptibility to hot cracking
- High resistance to intergranular corrosion
|
Electrode |
C% |
Cr% |
Ni% |
Mo% |
Mn% |
Si% |
P% |
S% |
FN |
|
AWS:E308L-17 Required |
≤0.04 |
18.0-21.0 |
9.0-11.0 |
≤0.75 |
0.5-2.5 |
≤1.00 |
≤0.04 |
≤0.03 |
-- |
|
GB:E308L-17 Require |
≤0.04 |
18.0-21.0 |
9.0-11.0 |
≤0.75 |
0.5-2.5 |
≤0.90 |
≤0.04 |
≤0.03 |
-- |
|
EASYARC® 308 |
0.02 |
20.14 |
9.21 |
0.061 |
0.71 |
0.86 |
0.023 |
0.009 |
6-10 |
|
Electrode |
Condition |
Tensile Strength(MPa) |
Elongation(%) |
|
AWS:E308L-17 Required |
As-welded |
≥520 |
≥35 |
|
GB:E308L-17 Require |
As-welded |
≥520 |
≥35 |
|
EASYARC® 308 |
As-welded |
635 |
49.5 |
|
Diameter x Length (mm x mm) |
Package-Weight(kg) |
|
|
Inner box |
Outer Carton |
|
|
2.5 x 300 3.2 x 350 4.0 x 350 5.0 x 350 |
4 5 5 5 |
16 20 20 20 |
|
Diameter x Length (mm x mm) |
Welding Position |
2.5 x 300 |
3.2 x 350 |
4.0 x 350 |
5.0 x 350 |
|
Current (A) |
1G,2G,2F |
50-85 |
80-120 |
100-150 |
140-180 |
|
3G up,4G |
45-80 |
70-110 |
90-140 |
-- |
