EASYARC® 6011
Product Application
- Suitable for fillet, butt & lap joint welding on sheet metal
- Mainly for sheet metal welding applications such as manufacturing, construction & maintenance work of vent pipe, flue pipe, oil tank, ships & vehicles
Welding Position
Standard
AWS A5.1/A5.1M: E6011
Literature
Literature
literature
Consumables Detail
- Cellulosic type mild steel electrode
- AC polarity welding are commended
- Stable arc with high arc force brings excellent weldability in all position including vertical down operation
- Outstanding bead appearance & easy slag removal
|
|
C |
Mn |
Si |
S |
P |
|
AWS requirements |
≦0.20 |
≦1.20 |
≦1.00 |
--- |
--- |
|
Typical value |
0.13 |
0.52 |
0.33 |
0.022 |
0.020 |
|
|
Yield Strength (MPa) |
Tensile Strength (MPa) |
Elongation (%) |
|
AWS requirements |
≧330 |
≧430 |
25 |
|
Typical value |
435 |
540 |
35 |
|
Dia. x Length (mm x mm) |
Weight / Inner box (KG) |
Weight / Outer carton (KG) |
|
2.5*300 |
5 |
20 |
|
3.2*350 |
5 |
20 |
|
4.0*350 |
5 |
20 |
|
|
|
2.5*300 |
3.2*350 |
4.0*350 |
|
Current (A)
|
AC |
40-90 |
60-120 |
110-150 |
