● General construction
● Pressure vessels and tubes
● Sheet metal applications
● Root pass pipe welding
ASME SFA-5.18 AWS A5.18 ER70S-6
Literature
Literature
● GTAW solid wire for mild steels
● Use with 100% Ar shielding gas
● High quality, pure and consistent raw rod
● Particularly good for root pass welding
|
MERIT® JG™-56 |
C |
Si |
Mn |
S |
P |
Cu |
|
AWS Requirements |
0.06-0.15 |
0.80-1.15 |
1.40-1.85 |
≤0.035 |
≤0.025 |
≤0.50 |
|
Typical value |
0.07 |
0.83 |
1.48 |
0.015 |
0.015 |
0.12 |
|
MERIT® JG™-56 |
Condition |
Shielding Gas |
Yield Strength |
Tensile Strength |
Elongation |
CVN Impact J@-30°C |
|
AWS Requirements |
As-welded |
100%Ar |
≥400 |
≥480 |
≥22 |
≥27 |
|
Typical value |
460 |
550 |
30 |
160 |
1.6×1000mm, 2.0×1000mm, 2.4×1000mm, 3.2×1000mm, 4.0×1000mm
STANDARD PACKAGING
Plastic Tube: 5KG, 10KG
* Please contact your local LINCOLN ELECTRIC® sales office for alternative types of packaging.
|
Diameter x Length (mm x mm) |
1.2x1000 |
1.6x1000 |
2.0x1000 |
2.4x1000 |
3.2x1000 |
4.0x1000 |
|
Current Range(A) |
120-180 |
140-200 |
160-240 |
180-260 |
220-280 |
240-300 |
